Fisher & Paykel CD13DG2 13cm Series 11 Modular Auxiliary Downdraft Extractor In Grey

Fisher & Paykel CD13DG2 13cm Series 11 Modular Auxiliary Downdraft Extractor delivers powerful, seamless benchtop extraction for modular cooking.

Designed as part of Fisher & Paykel’s unique modular cooking solution, the Fisher & Paykel CD13DG2 downdraft extractor integrates neatly into your benchtop without the need for overhead ventilation. Pair it with a Primary Modular Induction Hob and compatible auxiliary hob modules to create a unified cooking setup tailored to your kitchen.

This auxiliary ventilation module is designed specifically for pairing with a Primary Modular Induction Hob and does not function independently. It is compatible with Fisher & Paykel 222mm x 89mm ventilation ducting accessories.

Why choose the Fisher & Paykel CD13DG2 auxiliary downdraft extractor?

Choose the CD13DG2 if you want a discreet Series 11 modular ventilation solution that sits in the benchtop rather than above the hob. Its key advantage is seamless integration with Fisher & Paykel modular cooktops, including automatic extraction linked to adjacent modules. Five fan speeds plus boost help clear steam and cooking odours, while the slim 13cm grey glass design suits refined, open-plan kitchens where overhead extraction is not the preferred look.

Flexible Modular Downdraft Ventilation

Enhance your cooking space with discreet downdraft ventilation positioned alongside your primary cooktop and auxiliary modules. The modular design gives you the flexibility to configure your cooking area around the way you live, cook and entertain.

The extractor provides seamless kitchen integration while helping maintain an open and uncluttered appearance. It is particularly suited to island hobs and open-plan kitchens where a traditional overhead cooker hood may be less practical.

Sleek Grey Glass Design

Integrated directly into the countertop alongside compatible hob modules, the CD13DG2 supports a clean, open-style kitchen design. Its subtle grey glass finish is designed to complement a wide range of contemporary kitchen schemes.

Automatic Link Mode Extraction

Simply open the cover to activate convenient extraction using Link Mode. The extractor links with adjacent hob modules and automatically adjusts the fan speed according to the power levels of nearby cooking zones, reducing the need for manual adjustment.

After cooking has finished, the fan can continue operating to capture remaining vapours and help keep the kitchen environment fresh.

Five Fan Speeds Plus Boost

With five fan speeds and a Boost function, this modular downdraft extractor provides effective removal of steam, cooking odours and grease. Operation is controlled through the primary module touchscreen, allowing the ventilation system to work discreetly alongside your cooking appliances.

Maximum air movement is 573m³/hr, with a maximum sound rating of 75dBA. At Speed 1, the sound rating is 42dBA.

Delayed Off Timer

A Delayed Off timer allows cooking smells and vapours to continue being extracted after you have finished cooking. The ventilation will automatically switch off after a preset period, helping to reduce unnecessary energy use if it is left running.

Easy-Clean Grease Filter

The nine-layer filter is designed to trap grease particles during extraction. The filter can be removed easily for cleaning and is dishwasher safe.

Installation details

This auxiliary ventilation module is designed to be paired with a Fisher & Paykel Primary Modular Induction Hob and does not operate independently. It is compatible with Fisher & Paykel 222mm x 89mm ventilation ducting accessories. The appliance measures 186mm high, 130mm wide and 530mm deep. Recirculation is optional. Detailed cut-out dimensions, clearance requirements and ducting configuration should be confirmed before installation.
