Elica BOXIN-HE-120 Boxin HE 120cm Built-In Extractor Hood in Stainless Steel & White Glass
- Elica Built-In Extractor Hood – Stainless steel and white glass cooker hood designed for discreet cabinet integration.
- Perimeter Aspiration – Concealed perimeter extraction delivers airflow up to 610m³/h.
- 3S Mechanical rotative – Three rotary speed settings provide simple control over extraction power.
- LED Hob Lighting – Two 2.5W 3500K LED lights deliver 381 lux across the cooking area.
- Easy to Maintain – Removable, washable grease and odour filters support straightforward routine cleaning.
£679.00
- Product Info
- Specification
- FAQ's
Shop the Elica Boxin HE 120cm extractor hood, model BOXIN-HE-120, with discreet cabinet integration and perimeter extraction up to 610m³/h.
Discreet 120cm Built-In Design
The Elica Boxin HE 120cm built-in extractor hood is designed to fit neatly beneath a kitchen cabinet, creating a streamlined, fully integrated appearance. Its T-shaped design optimises cabinet space, while the stainless steel and white glass finish complements modern kitchen interiors.
Subtle and carefully considered, this wide integrated extractor hood blends with the underside of the cabinet without compromising everyday extraction performance.
Why choose the Elica BOXIN-HE-120 built-in extractor hood?
Choose the BOXIN-HE-120 if you want a wide, discreet hood for a 120cm cooking area. It integrates into the wall unit while using perimeter extraction and protective white-glass panels to help keep cabinetry cleaner. With 3-speed mechanical controls, LED lighting, removable washable filters and up to 610m³/h airflow, it suits busy kitchens that value simple operation, strong coverage and a clean stainless-steel finish.
Perimeter Extraction up to 610m³/h
Concealed perimeter aspiration distributes extraction around the edge of the hood, providing airflow of up to 610m³/h. The extraction area remains hidden behind the glass panel, maintaining the clean appearance of this 120cm integrated cooker hood.
A high-performance motor helps remove cooking vapours, while three mechanical rotary speed settings allow you to adjust the extraction power to suit your cooking.
LED Hob Lighting
Two 2.5W 3500K LED lights provide 381 lux across the cooking area, helping to improve visibility while preparing meals. The efficient lighting is neatly integrated into the Elica built-in cooker hood for a practical and uncluttered finish.
Added Cabinet Protection
A central glass panel and two side glass panels help protect surrounding wall units from cooking vapours. Together with the ergonomic front visor, these panels reduce exposure to moisture and help prevent potential wear to the cabinetry.
The hood can be installed at a minimum height of 50cm above gas hobs, supporting effective cabinet protection while maximising the available kitchen space.
Easy-to-Maintain Filters
Removable grease and odour filters make routine care more straightforward. The filters are washable and replaceable, helping to maintain hygiene, extraction performance and the lifespan of the appliance.
| Weight | 17.2 kg |
|---|---|
| Dimensions | 31 × 120 × 37 cm |
| Automatic Programmes | No |
| Brand | Elica |
| Smart Appliance | No |
| Energy Efficiency Class | B |
| Colour Group | Stainless Steel |
| Noise Level | 70 |
| No. Of Fan Speeds | 3 |
| Outlet Type | Duct Out or Recirculation |
| Warranty | 2 |
| Group | Built In |
| Variant | Wall |
| Product Type | Cooker Hood |
| SKU | BOXIN-HE-120 |
| GTIN | 8020283036437 |
| Brand | Elica |
|---|---|
| Product Type | Built-In Extractor Hood |
| Model | BOXIN-HE-120 |
| Manufacturer Reference | PRF0097797A |
| EAN | 8020283036437 |
| Finish | Stainless steel and white glass |
| Width | 120cm |
| Weight | 17.2kg |
| Energy Rating | B |
| Extraction Type | Perimeter aspiration |
| Airflow | 230m³/h – 610m³/h |
| Noise Level | 49dB(A) – 70dB(A) |
| Controls | 3-speed mechanical rotary controls |
| Lighting | 2 x 2.5W LED lights, 3500K, 381 lux |
| Power | 255W |
| Duct Transition | 150mm |
| Filters | Removable, washable grease and odour filters |
| Key Features | Discreet cabinet integration, T-shaped design, perimeter extraction, LED hob lighting, central and side glass cabinet protection panels |
Installation details
Designed for discreet built-in installation beneath a kitchen wall unit. Minimum installation distance is 50cm from induction, radiant and gas hobs. Duct transition is 150mm and rated absorption is 255W. Full cut-out dimensions, electrical connection details and clearance requirements are not provided and should be confirmed before installation.
Frequently Asked Questions About the BOXIN-HE-120
Is the Elica BOXIN-HE-120 fully integrated into a kitchen cabinet?
Yes. This built-in extractor hood is designed to fit into a wall unit and sit flush with the underside of the cabinet. Its stainless steel and white glass finish remains visible from below, while the motor and main body are concealed within the cabinetry.
How wide is the Elica Boxin HE 120 cooker hood?
This model has a nominal width of 120cm and a listed overall width of approximately 119.4cm. It is intended for wide cooking areas, but the cabinet opening and installation dimensions should be checked against the fitting diagram before ordering.
What is the maximum extraction rate?
The Elica BOXIN-HE-120 provides an airflow range of 230m³/h to 610m³/h. Three extraction speeds allow the airflow to be adjusted for anything from light simmering to cooking that produces more steam and odours.
What does perimeter aspiration mean?
Perimeter aspiration draws cooking vapours through openings around the edge of the white glass panel rather than through an exposed central grille. This conceals the extraction area and helps maintain the hood’s streamlined integrated appearance.
How noisy is the Elica BOXIN-HE-120?
The stated noise level ranges from 49dB(A) at the lowest setting to 70dB(A) at maximum extraction. Selecting a lower speed during lighter cooking helps reduce operating noise.
Can this cooker hood be installed for extraction or recirculation?
Yes. It can vent cooking vapours outside through suitable ducting or operate in recirculation mode with a compatible charcoal odour filter. Charcoal filters and any installation accessories required for recirculation are sold separately.
Which filters are compatible with the Elica BOXIN-HE-120?
A removable aluminium grease filter is included. For recirculating installation, Elica lists the CFC0140343 charcoal filter and the CFC0162221 regenerable long-life charcoal filter as compatible options.
Are the filters washable?
The aluminium grease filter is removable and washable. The compatible regenerable long-life odour filter can also be cleaned and regenerated according to Elica’s maintenance instructions. A standard charcoal filter should be replaced at the recommended interval rather than treated as a washable filter.
What clearance is required above the hob?
Elica specifies a minimum installation distance of 50cm above both induction or radiant electric hobs and gas hobs. The hood must also be fitted in accordance with the installation manual and any requirements supplied with the hob.
What size ducting does the Elica Boxin HE 120 require?
The hood has a 150mm duct outlet. Using correctly sized ducting with a short, direct route helps support effective airflow and reduce unnecessary operating noise.
What lighting and controls does this model have?
Two 2.5W LED lights provide warm-neutral 3500K illumination rated at 381 lux across the cooking area. Extraction is controlled using straightforward mechanical rotary controls with three speed settings.
What are the energy rating, power consumption and warranty?
The Elica BOXIN-HE-120 has a B energy rating and a total connected power of 255W. The UK model is supplied with a two-year parts and labour manufacturer’s warranty.
Are there any suitable alternatives to the Elica BOXIN-HE-120 Boxin HE 120cm Built In Extractor Hood I could consider?
Yes, you could consider the Elica BOXIN-LX-120 Boxin LX 120cm Built In Extractor Hood as a more affordable same-brand option with the same 120cm built-in format, three speeds and similar extraction performance.
Alternatively, the Elica BOXIN-AD-120 Boxin Advance 120cm Built In Extractor Hood is a higher-function choice with an intensive setting, AIRMATIC automatic activation, stronger extraction and quieter operation.
*FAQs are checked against manufacturer information, but please confirm installation requirements before purchase.
