Smeg Universal 72cm Integrated Cooker Hood Stainless steel KSG74B
- Re-circulating or Ducted Out
- Automatic switch off function
- Maximum extraction 592m³/h (Intensive)
- Maximum noise level 67dB
Complete the form below and our team will do their best to help
or simply call us on
- Product Info
- Specification
Smeg Universal 72cm Integrated Cooker Hood Stainless steel KSG74B
DUCTING OR RE-CIRCULATING
Most Smeg hoods offer the choice of ducting or re-circulating, so you can choose your preferred method.
Ducting out extracts cooking fumes and expels them outside, using a vent kit (available as an optional accessory) The diameter of the ducting hose should match the vent outlet of the hood.
SP150 – Simple vent kit for hoods with a 150mm diameter vent outlet
SP150FLAT – Comprehensive vent kit for hoods with a 150mm diameter vent outlet
SP215 – Simple vent kit for hoods with a 120mm diameter vent outlet
SP217 – Comprehensive vent kit for hoods with a 120mm diameter vent outlet
Re-circulating extracts the cooking fumes and passes them through active charcoal filters (available as an optional accessory), recirculating the cleaned air back into the room. To find out which charcoal filter your hood needs, check the accessory tab on the hoods specification.
INTENSIVE EXTRACTION
A powerful intensive speed can be selected when quick extraction is needed, whether you’re creating a sizzling stir fry or preparing an aromatic curry, even the strongest cooking odors will be removed in no time.
LED LIGHTING
These lights are long lasting, save money and perfectly illuminate the work surface below. They can be switched on regardless of the fans, and used simply to create ambience lighting in the kitchen.
STAINLESS STEEL FILTERS
Easy cleaning with washable stainless steel metal grease filter(s) which can be put in the dishwasher.
AUTOMATIC SWITCH OFF
A special setting switches off both the extraction and the lights, after a predefined time, during which the hood keeps on purifying the air until it turns off automatically.
| Automatic Programmes | No |
|---|---|
| Brand | Smeg |
| Smart Appliance | No |
| Discontinued | Yes |
| Warranty | 2 |
| SKU | 178e2fa8d845 |
| GTIN | 8017709226183 |
TYPE
- Product family: Hood
- Hood Type: Integrated hood
- Hood width: 72 cm
- Extraction: Expulsion
- Electronic control: Yes
- Perimeter extraction: Yes
- EAN code: 8017709226183
AESTHETICS
- Colour: Stainless steel
- Finishing: Glass
- Aesthetics: Universal
- Design: Fully integrated
- Material: Stainless Steel + Glass
- Type of steel: Brushed
- Glass Type: White
PROGRAMS / FUNCTIONS
- No. of speeds: 3
- Intensive speed: Yes
- Time-setting options: Automatic switch-off
CONTROLS
- Control setting: Electronic buttons
- Led colour: White
TECHNICAL FEATURES
- No. of lights: 2
- Light type: LED
- Light power: 1 W
- Light color temperature scale (°K): 4000 °K
- Free outlet maximum capacity: 750 m³/h
- Motor power: 235 W
- No. of filters: 1
- Anti-grease filters: stainless steel 7 layer
- Minimum distance from GAS hob: 650 mm
- Vent outlet: 150 mm
- Minimum distance from ELECTRIC hob: 650 mm
- Non return valve: Yes
PERFORMANCE / ENERGY LABEL
- Energy efficicency class ( EEC): B
- Fluid Dynamic Efficiency class (FDEC): C
- Grease Filtering Efficiency Class (GFEC): D
- Lighting Efficiency Class (LEC): A
- Annual Efficiency Consumption (AEChood): 68 KWh/year
- Fluid Dynamic Efficiency (FDE): 22.6
- Lighting Efficiency (LE): 68 lux/W
- Grease Filtering Efficiency (GFE): 65.9 %
- Air flow at minumum speed (Qmin): 247 m³/h
- Maximum extraction rate: 450 m³/h
- Intensive extraction rate: 592 m³/h
- Airbourne acouistical A-weighted sound Power Emission at minimum speed (SPEmin): 47 dB(A)
- Airborne acoustical A-weighted sound Power Emission at maximum speed (SPEmax): 60 dB(A)
- Airbourne acoustical A-weighted sound power emission at boost speed (SPEboost): 67 dB(A)
- Power consumption in stand-by mode (Ps): 0.49 W
- Time increase factor (F): 1.00
- Energy Efficiency Index per first cavity: 57.2
- Measured air flow rate at best efficiency point (Qbep): 344 m³/h
- Measured air pressure at best efficiency point (Qbep): 437 Pa
- Measured electric power input at best efficiency point (Wbep): 154 W
- Normal Power of the light system (Wl): 2 W
- Average illumination of the light on the cooking surface (Emiddle): 118 lux
- Sound power level at highest setting (Lwa): 60 dB(A)
ELECTRICAL CONNECTION
- Nominal power: 238 W
- Voltage: 220-240 V
- Frequency (Hz): 50-60 Hz
- Power supply cable length: 1000 mm
SPEED 1
- Extraction rate IEC 61591: 280 m³/h
- Noise level IEC 60704-2-13: 48 dB(A)
- Power: 140 W
SPEED 2
- Extraction rate IEC 61591: 367 m³/h
- Noise level IEC 60704-2-13: 55 dB(A)
- Power: 165 W
SPEED 3
- Extraction rate IEC 61591: 480 m³/h
- Noise level IEC 60704-2-13: 61 dB(A)
- Power: 190 W
INTENSIVE SPEED
- Extraction rate (IEC 61591): 700 m³/h
- Noise level IEC 60704-2-13: 68 dB(A)
- Power: 230 W
LOGISTIC INFORMATION
- Dimensions of the product (mm): 275x734x272
- Width: 734 mm
- Depth (mm): 272 mm
- Product Height (mm): 275 mm
