Miele DA2808 90cm Built In Extractor Hood
Miele DA2808 90cm Built In Extractor Hood
Miele DA2808 90cm Built In Extractor Hood
Miele DA2808 90cm Built In Extractor Hood
Miele DA2808 90cm Built In Extractor Hood
DA2808
Miele DA2808 90cm Built In Extractor Hood
  • Brilliant White Finish Miele Ceiling Extractor Hood – Duct Out or Recirculation (sold separately), Remote control operation (not included), Run-On function, Filter Indicator & Noise Rating of just 57dB(A) with Energy Rating A+.
  • Stainless Steel (10-ply) Grease Filter – Can be cleaned in Dishwasher.
  • Powerful – 725 m3/h on booster setting.



£2,479.00
Appliance Superstore - Price Match
Appliance Superstore Clearance Sale - Kitchen Appliance Clearance Sale
Product info
Specification
Downloads

Discover the Miele DA2808 90cm Built In Ceiling Extractor Hood in Brilliant White on Appliance Superstore. Brilliant White Finish Miele Ceiling Extractor Hood - Duct Out or Recirculation (sold separately), Remote control operation (not included), Run-On function, Filter Indicator & Noise Rating of just 57dB(A) with Energy Rating A+. Stainless Steel (10-ply) Grease Filter - Can be cleaned in Dishwasher. Powerful - 725 m3/h on booster setting. Energy Efficient - LED Lighting. Miele CleanCover - Easy cleaning & Protects electrical components + motor. Miele@Home - Make your life smart; connect up all your Miele appliances using your smart devices.

STAINLESS STEEL GREASE FILTERS (10-LAYER) - Easy to use and effective against grease

Miele cooker hoods are equipped with 10-ply stainless-steel grease filter(s) for excellent grease removal. Built-in fall protection allows you to handle them safely and protects your hob from damage. The top layer and filter frame are made of high-quality stainless steel so that no visible discolouration occurs from being cleaned in the dishwasher and they retain their stunning appearance.

MIELE CLEANCOVER - Convenience and safety in detail

Located behind the grease filters is the Miele CleanCover: Instead of sharp metal edges and electrical components you will find only a sealed, smooth surface. It is particularly easy to clean and protects you from coming in contact with cables and motor components. Miele attention to detail - for your convenience and safety.

SAFETY SWITCH-OFF - Always on the safe side

The cooker hood will switch off automatically after 10 hours. This ensures maximum safety even in the event of operating errors.

ECO MOTOR - The heart of every cooker hood

The heart and soul of every cooker hood is the motor. Some Miele cooker hoods feature ECO motors which work up to 50 % more economically than conventional motors. They are also very quiet but still as powerful as the motors in other Miele cooker hoods.

CON@CTIVITY (Miele@Home) - Automatic operation for intelligent fan control

Thanks to the Con@ctivity automatic function, the cooker hood can communicate with the hob below: the settings selected on the hob are transmitted to the controls on the cooker hood. Your Miele cooker hood then uses this data to automatically select the correct fan setting, ensuring the optimum room climate at all times. Communication is established between the cooker hood and hob via WiFi.

RUN-ON FUNCTION - Automatic fan run-on

The automatic fan run-on ensures the full extraction of steam and odours still in the air after cooking. The cooker hood can be set to switch off automatically after 5 or 15 minutes.

FILTER INDICATOR - Countdown time conveniently in view

If the grease or active charcoal filter of your Miele cooker hood is saturated, it is indicated by a lit-up red LED. Your filter should then be cleaned or replaced as soon as possible. You can individually adjust the factory-set service life of the filters: The grease filter saturation indicator can be programmed for 20, 30, 40 or 50 hours, the indicator for active charcoal filter replacement for 120, 180 or 240 hours.

EDGE EXTRACTION - Decorative panels instead of metal grease filters

In cooker hoods with edge extraction panels, the commercial-looking metal grease filters are hidden behind a decorative cover. The cooking vapours are drawn in at the outer edges.

Brand Miele
Code DA2808
GTIN 4002516003465
Type Cooker Hood
Finish White
Group Ceiling
Size 90cm to 119cm
Energy Efficiency Class A+
Warranty 2 Years
Connectivity Smart Appliance
Noise Rating 50dB to 69dB
Variant Ceiling
Outlet Type Duct Out or Recirculation
Height 35cm
Width 90cm
Depth 50cm
Dimensions H 34.2cm W 88cm D 50cm
Noise Level dB 57dB
No. Of Fan Speeds 4
Intensive Mode Yes
Colour Group White
Category Cooker Hoods

SPECIFICATION

CONSTRUCTION TYPE

Ceiling extractor

OPERATING MODES

Type of air guide Can be retrofitted
Recirculation conversion kit (order separately) DUU 2900
Active charcoal filter (order separately) DKF 20-P

DESIGN

Colour Brilliant white
Edge extraction

USER CONVENIENCE

Miele@home
Automatic function Con@ctivity
Electronic controls
Miele@mobile app
Power levels (number without Booster level) 3
Programmable Booster level switch-off
Run-on time 5/15 min.
Grease filter saturation indicator
Grease filter saturation indicator programmable
Active charcoal filter saturation indicator programmable

EFFICIENCY AND SUSTAINABILITY

Energy efficiency class (A+++ to D) A+
Annual energy consumption in kWh/year 27.60
Fluid dynamic efficiency class A
Lighting efficiency class A
Grease filtering efficiency class B
PowerManagement system
ECO motor

CLEANING AND CARE

Easy-to-clean canopy interior – CleanCover

FILTER SYSTEM

Number of dishwasher-safe stainless steel grease filters (10-ply) 2

LIGHTING

LED
Number x W 4 x 3 W
Light intensity in Lx 720 lx
Colour temperature in K 3500 Kelvin
Dimmer function

FAN

Dual-action blower
DC motor

EXHAUST AIR

Air throughput in Level 1 (m³/h) according to EN 61591 200
Air throughput in Level 2 (m³/h) according to EN 61591 310
Air throughput in Level 3 (m³/h) according to EN 61591 450
Air throughput in booster level 1 (m³/h) 725
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 35
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 44
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 53
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3 65
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 20
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 30
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 38
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13 50

RECIRCULATION

Air throughput in Level 1 (m³/h) according to EN 61591 115
Air throughput in Level 2 (m³/h) according to EN 61591 215
Air throughput in Level 3 (m³/h) according to EN 61591 335
Air throughput in Booster level 1 (m³/h) according to EN 61591 535
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 43
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 53
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 62
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3 72
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 28
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 39
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 47
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13 57

SAFETY

Safety shut-off

TECHNICAL DATA

339
339
Overall height for vented and external in in. (mm) 339
Overall height for extraction mode and external mode cooker hoods in mm 339
Overall height for recirculation in in. (mm) 339
Overall height for recirculation mode cooker hoods in mm 339
Canopy width in in. (mm) 880
Canopy height in in. (mm) 342
Depth of hood canopy in in. (mm) 500
Minimum height above electric hobs in mm 450
Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm 650
Net weight in kg 17
Length of supply lead in m 1.50
Standard plug fitted
Total rated load in kW 0.12
Voltage in V 230
Fuse rating in A 10
Frequency in Hz 50
Number of phases 1

INSTALLATION NOTES

Extraction ducting connection at top
Extraction ducting connection on side
Extraction ducting connection at top, rear, and si
Diameter of extraction ducting connection in mm 150
Combination with WiFi-enabled Miele hob required

ACCESSORIES INCLUDED

Non-return flap
Adapter to reduce ducting diameter from 150 mm to 125 mm Ø

EAN

4002516003465
