- Stainless Steel (10-ply) Grease Filter - Can be cleaned in Dishwasher
- Powerful - 600 m3/h on booster setting
- Auto Fan Run-On - Switched off automatically after a 5 or 15 minute run-on period post cooking
- Miele@Home - Communicates with the hob below: Settings on the hob are transmitted to the controls on the cooker hood
Automatic operation for intelligent fan control
Thanks to the Con@ctivity automatic function, the cooker hood can communicate with the hob below: the settings selected on the hob are transmitted to the controls on the cooker hood. Your Miele cooker hood then uses this data to automatically select the correct fan setting, ensuring the optimum room climate at all times. Communication between the hob and hood is established either via ZigBee (Con@ctivity 2.0) or WiFi (Con@ctivity 3.0).
Convenience and safety in detail
Located behind the grease filters is the Miele CleanCover: Instead of sharp metal edges and electrical components you will find only a sealed, smooth surface. It is particularly easy to clean and protects you from coming in contact with cables and motor components. Miele attention to detail - for your convenience and safety.
Programmable maximum power
The Booster setting provides very high air flow and is only intended for brief operation, for example, when heavy smoke or strong odours develop when food is burned. The Booster setting can be programmed so that the fan automatically switches back to Setting 3 after 5 minutes. This avoids unnecessary energy consumption.
Particularly powerful
Miele cooker hoods are equipped with high-quality radial fans that provide suction on two sides. These high-performance units guarantee powerful air throughput at all times as well as optimised extraction. Despite their high performance, the fans operate at a comfortably low noise level.
| Brand | Miele |
| Code | DA2578 |
| GTIN | 4002515978276 |
| Type | Cooker Hood |
| Energy Efficiency Class | A |
| Finish | Stainless Steel |
| Group | Built In |
| Size | 60cm to 89cm |
| Warranty | 2 Years |
| Connectivity | Smart Appliance |
| Noise Rating | 50dB to 69dB |
| Variant | Wall |
| Outlet Type | Duct Out or Recirculation |
| Height | 5cm |
| Width | 70cm |
| Depth | 40cm |
| Dimensions | H 5cm W 70.2cm D 40.2cm |
| Noise Level dB | 55dB |
| No. Of Fan Speeds | 4 |
| Intensive Mode | Yes |
| Colour Group | Metallic |
| Category | Cooker Hoods |
Construction type
- Integrated extractor
Networking of domestic appliances
- WiFiConn@ct
- MobileControl
- ShopConn@ct
Operating modes
- Type of air guide Convertible
- Recirculation conversion kit (order separately) DUU 151
- Active charcoal filter (order separately) DKF15-1
Design
- Colour Stainless steel
- RAL colours available as customisation on request
- Customisation possible on request
- Variable height available as customisation on request
- Variable width available as customisation on request
User convenience
- Miele@home
- Automatic function Con@ctivity 3.0 (WLAN)
- Electronic controls
- Light-touch switches with LED
- Miele@mobile app
- Power levels (number without Booster level) 3
- Booster level
- Programmable Booster level switch-off
- Grease filter saturation indicator
- Grease filter saturation indicator programmable
- Active charcoal filter saturation indicator programmable
Efficiency and sustainability
- Energy efficiency class (A+++ to D) A
- Annual energy consumption in kWh/year 51.70
- Fluid dynamic efficiency class A
- Lighting efficiency class A
- Grease filtering efficiency class B
Cleaning convenience
- Easy-to-clean canopy interior – CleanCover
Filter system
- Number of dishwasher safe stainless-steel grease filters (10-ply) 2
Lighting
- LED
- Number x W2 x 3 W
- Light intensity in Lx 300 lx
- Colour temperature in K 3000 Kelvin
Blower
- Dual-action blower
- AC motor
Extraction
- Air throughput in Level 1 (m³/h) according to EN 61591250
- Air throughput in Level 2 (m³/h) according to EN 61591300
- Air throughput in Level 3 (m³/h) according to EN 61591360
- Air throughput in Booster level (m³/h) according to EN 61591600
- Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-347.00
- Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-351.00
- Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-356.00
- Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-367.00
- Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1332.00
- Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1337.00
- Sound pressure in setting 3 (dB(A) re 20 µPa)41.00
- Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-1352.00
Recirculation
- Air throughput in Level 1 (m³/h) according to EN 61591200
- Air throughput in Level 2 (m³/h) according to EN 61591250
- Air throughput in Level 3 (m³/h) according to EN 61591320
- Air throughput in Booster level (m³/h) according to EN 61591530
- Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-355.00
- Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-359.00
- Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-363.00
- Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-372.00
- Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1339.00
- Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1344.00
- Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1348.00
- Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-1357.00
Safety
- Safety shut-off
Technical data
- Canopy width in in. (mm) 702
- Canopy height in in. (mm) 50
- Depth of hood canopy in in. (mm) 402
- Minimum height above electric hobs in mm 450
- Minimum height above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm 650
- Net weight in kg 11.60
- Length of supply lead in m 1.50
- Standard plug fitted
- Total rated load in kW 0.23
- Voltage in V 230
- Fuse rating in A 10
- Frequency in Hz 50
- Number of phases 1
Installation notes
- Extraction ducting connection at top
- Extraction ducting connection at rear
- Extraction connection at top and rear
- Diameter of extraction ducting connection in mm 150
- Combination with WiFi-enabled Miele hob recommended
